The PPTEC-ENERGY industrial vaporizers are fully automatic dry-running vaporizers with capacities of 40, 60, 80, 100, 120, 140, and 160 kg/h.

They feature precise heating temperature control and monitoring via PT100 sensors and redundant flood protection. For maximum operational safety, each vaporizer is equipped with a solenoid valve controlled by the PT100 sensor and a float switch in the internal liquid separator. Additionally, overheat protection with safety shutdown ensures safe operation.

The units are delivered ready for use and come equipped with filters, pressure gauges, thermometers, and ball valves at the inlet and outlet.

The electrical equipment complies with DIN VDE 100 for Ex Zone II.

Key Technical Advantages of PPTEC-ENERGY Industrial Vaporizers:

• Constant monitoring and control of temperature, pressure, flood protection, and capacity without additional upstream or downstream equipment
• Highly precise temperature monitoring via a centrally installed PT100 sensor inside the vaporizer body
• Simple and flexible operating temperature adjustment
• Each vaporizer includes an integrated liquid separator, complete with drain connection and ball valve
• The liquid separator also functions as a mechanical safety element (flood protection)
• Visual operational monitoring: indicators for heating operation (On/Off) and solenoid valve position (Open/Closed)
• Cleaning connection allows maintenance without disassembly or operational interruption
