BLACKMER HD compressors for industrial cases and applications
BLACKMER HD-Serie – pistons gas compressors
BLACKMER HD Series – Piston Gas Compressors
The BLACKMER HD Series piston gas compressors provide efficient and quiet handling of oil-free industrial gases or air. These single- and two-stage industrial gas compressors are specifically designed for industrial gas applications, combining modern engineering with high-quality materials to deliver maximum performance with minimal maintenance.
With a wide range of options and models, HD compressors can be customized to meet the exact requirements of specific applications.
Components made from ductile iron and stainless steel ensure robustness and strength, extending the service life of the compressors under all operating conditions.
The BLACKMER HD Series is available in two model variants:
- HD – Air-cooled compressors
- HDL – Liquid-cooled compressors
Air-cooled HD models are suitable for most applications, particularly low compression ratio operations and liquefied gas transfer. HDL models feature liquid-cooled cylinders and cylinder heads, designed for high-demand applications.
The HD Series is engineered to handle a wide variety of industrial gases, including:
Ammonia, Argon, Butadiene, Butane, Carbon Dioxide, Chlorine, Ethane, Ethanol, Helium, Hydrogen, Hydrogen Chloride, Isobutene, Methyl Chloride, Nitrous Oxide, Nitrogen, Propylene, Refrigerants, Sulfur Dioxide, Vinyl Chloride, and many more.
Single-Stage BLACKMER Compressors – HD (Air-Cooled) and HDL (Liquid-Cooled)
|
MODEL
|
|
|
|
HD602 HDL602 |
|
|
|
|
|
number of cylinder |
1 |
2 |
2 |
2 |
2 |
2 |
2 |
2 Double Acting |
|
piston strocke, mm |
63 |
63 |
76 |
102 |
76 |
76 |
102 |
102 |
|
MWAP, bar |
24.1 |
24.1 |
24.1 |
24.1 |
68.9 |
51.7 |
51.7 |
24.1 |
|
MIN/MAX RPM |
350/825 |
|||||||
|
pistons displacement m³/St |
|
|
|
|
|
|
|
|
|
Max KW |
5 |
7,5 |
11 |
30 |
11 |
11 |
30 |
37 |
|
weight, aprx, kg |
97 |
102 |
166 |
320 |
175 |
175 |
320 |
410 |
|
INLET/OUTLET |
3/4 NPT |
3/4 NPT |
1,5” ANSI 300 |
2” ANSI 300 |
1,5” ANSI 300 |
1,5” ANSI 300 |
2” 600 ANSI |
2” 600 ANSI |
Two-Stage Compressors – HD (Air-Cooled) and HDL (Liquid-Cooled)
|
MODEL |
|
|
|
|
number of cylinder /stage |
1 |
||
|
piston diameter, mm |
|
|
|
|
piston strocke, mm |
63,5 |
76 |
102 |
|
MWAP, bar |
42,4 |
42,4 |
28,6 |
|
MIN/MAX RPM |
350/825 |
||
|
pistons displacement m³/St |
|
|
|
|
Max KW |
7,5 |
11 |
30 |
|
Weight, aprx, kg |
111 |
184 |
352 |
|
INLET/OUTLET, NPT |
3/4-3/4 |
1-1/4 / 1 |
2 / 1-1,5 |
HD080-Serie – pistons gas compressor
Model: HD082
BLACKMER HD080 Series – HD082 Single-Stage Air-Cooled Compressor
The BLACKMER HD080 Series includes the HD082, the smallest available model in the HD Series. This compressor delivers a capacity of 8.45 CFM (14.35 m³/h) at maximum speed.
This single-stage, air-cooled compressor is particularly suited for low compression ratio operations and industrial liquefied gas transfer applications.
For precise leak control and minimization of product contamination, the HD082 is equipped with a double seal.
Additionally, HD compressors feature:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series therefore delivers maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
HD160-Serie – pistons gas compressor
Modelle: HD161, HD162, HD163
BLACKMER HD160 Series – Single-Stage, Two-Cylinder Air-Cooled Compressors
The Blackmer HD160 Series consists of single-stage, two-cylinder, air-cooled piston gas compressors, delivering a capacity of 16.9 CFM (28.7 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the HD160 compressors are available in different seal configurations:
- HD161 – Single Seal
- HD162 – Double Seal
- HD163 – Triple Seal
Compared to competitor models, all HD compressors feature thicker and more robust wear parts—including piston rings, needle bearings, and high-efficiency valves—allowing for longer operating intervals between maintenance.
Additionally, the HD compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The BLACKMER HD Series delivers maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
HD170-Serie – piston s gas compressors
Model: HD172, HDL172, HD173, HDL173
BLACKMER HD170 Series – Two-Stage Piston Gas Compressors
The Blackmer HD170 Series consists of two-stage piston gas compressors and is available in both air-cooled models (HD172/HD173) and liquid-cooled models (HDL172/HDL173). The compressors provide a capacity of 8.42 CFM (14.3 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the following seal options are available:
- HD172 / HDL172 – Double Seal
- HD173 / HDL173 – Triple Seal
Compared to competitor compressors, all HD models feature thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, enabling longer operating intervals between maintenance.
Additionally, HD170 compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series ensures maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
BLACKMER HDL320-Serie – pistons gas compressors
Model: HDL322, HDL323
BLACKMER HDL320 Series – Liquid-Cooled, Single-Stage Two-Cylinder Compressors
The liquid-cooled Blackmer HDL320 Series consists of single-stage, two-cylinder piston gas compressors, delivering a capacity of 9 CFM (23.1 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the HDL322 model is equipped with a double seal.
Compared to competitor compressors, all HD Series models feature thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, allowing for longer operating intervals between maintenance.
Additionally, HDL320 compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series ensures maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
BLACKMER HDL340-Serie – pistons gas compressors
Model: HDL342, HDL343
BLACKMER HDL340 Series – Liquid-Cooled, Single-Stage Two-Cylinder Compressors
The liquid-cooled Blackmer HDL340 Series consists of single-stage, two-cylinder piston gas compressors, delivering a capacity of 16.25 CFM (41.28 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the following seal options are available:
- HDL342 – Double Seal
- HDL343 – Triple Seal
Compared to competitor compressors, all HD Series models feature thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, allowing for longer operating intervals between maintenance.
Additionally, HDL340 compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series ensures maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
BLACKMER HD370-Serie – pistons gas compressor
Model: HD372, HDL372, HD373, HDL373
BLACKMER HD370 Series – Two-Stage Piston Gas Compressors
The Blackmer HD370 Series consists of two-stage piston gas compressors and is available in both air-cooled models (HD372/HD373) and liquid-cooled models (HDL372/HDL373). The compressors deliver a capacity of 24.1 CFM (40.8 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the following seal options are available:
- HD372 / HDL372 – Double Seal
- HD373 / HDL373 – Triple Seal
Compared to competitor compressors, all HD Series models feature thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, allowing for longer operating intervals between maintenance.
Additionally, HD370 compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series guarantees maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
BLACKMER HD600-Serie – piston gas compressor
Modelle: HD602, HDL602, HD603, HDL603
Blackmer HD600 Series – Single- and Two-Stage Two-Cylinder Piston Gas Compressors
The Blackmer HD600 Series includes single- and two-stage, two-cylinder piston gas compressors and is available in four model variants:
- HD602 / HD603 – Air-Cooled
- HDL602 / HDL603 – Liquid-Cooled
The compressors deliver a capacity of 64.2 CFM (109 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the following seal options are available:
- HD602 / HDL602 – Double Seal
- HD603 / HDL603 – Triple Seal
In addition, the HD600 and HD940 models feature the S3R oil control seal system, which retains oil in the crankcase and prevents oil migration within the compressor.
Compared to competitor compressors, all HD Series models are equipped with thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, enabling longer operating intervals between maintenance.
BLACKMER HD610-Serie – pistons gas compressor
Model: HD612, HDL612, HD613, HDL613
BLACKMER HD610 Series – Two-Stage Piston Gas Compressors
The Blackmer HD610 Series consists of two-stage piston gas compressors and is available in both air-cooled models (HD612/HD613) and liquid-cooled models (HDL612/HDL613). The compressors provide a capacity of 53.7 CFM (91.2 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the following seal options are available:
- HD612 / HDL612 – Double Seal
- HD613 / HDL613 – Triple Seal
Compared to competitor compressors, all HD Series models feature thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, enabling longer operating intervals between maintenance.
Additionally, HD610 compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series guarantees maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
BLACKMER HDL640-Serie – pistons gas compressor
Model: HDL642, HDL643
BLACKMER HDL640 Series – Liquid-Cooled, Single-Stage Two-Cylinder Compressors
The liquid-cooled Blackmer HDL640 Series consists of single-stage, two-cylinder piston gas compressors, delivering a capacity of 31.7 CFM (53.8 m³/h) at maximum speed.
For precise leak control and minimization of product contamination, the following seal options are available:
- HDL642 – Double Seal
- HDL643 – Triple Seal
Compared to competitor compressors, all HD Series models feature thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, enabling longer operating intervals between maintenance.
Additionally, HDL640 compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series ensures maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
BLACKMER HD940-Serie – pistons gas compressor
Model: HD942, HDL942, HD943, HDL943
BLACKMER HD940 Series – Largest Piston Gas Compressors
The Blackmer HD940 Series represents the largest range of piston gas compressors, delivering a capacity of 125.2 CFM (212 m³/h) at maximum speed.
These are single-stage, double-acting, two-cylinder compressors, available in both air-cooled models (HD942/HD943) and liquid-cooled models (HDL942/HDL943).
For precise leak control and minimization of product contamination, the following seal options are available:
- HD942 / HDL942 – Double Seal
- HD943 / HDL943 – Triple Seal
In addition, the HD600 and HD940 models feature the S3R oil control seal system, which retains oil in the crankcase and prevents oil migration within the compressor.
Compared to competitor compressors, all HD Series models are equipped with thicker and more robust wear parts, including piston rings, needle bearings, and high-efficiency valves, allowing for longer operating intervals between maintenance.
Additionally, HD940 compressors are equipped with:
- Cylinder head and cylinders made of ductile iron
- Steel pistons
- Self-adjusting piston rod seals
The HD Series guarantees maximum performance, energy efficiency, quiet operation, low maintenance costs, and high reliability, even under extremely demanding operating conditions.
